The twist drill is the most common type of drill bit used for drilling holes in wood, metal, and plastic. It features a cylindrical shaft with helical or spiral flutes that wrap around the body. These flutes are designed to channel debris and swarf (chips) out of the hole as the bit cuts.
Materials and Construction
Twist drill bits are manufactured using different materials depending on the hardness of the surface they are intended to drill into:
- High-Speed Steel (HSS): The standard workhorse bit for home DIY and general shop use. It performs excellently on wood, plastics, aluminum, and mild steel.
- Cobalt (M35 HSS): An HSS alloy mixed with cobalt that greatly increases heat resistance. Ideal for drilling harder metals like cast iron or stainless steel.
- Titanium-Coated: Standard HSS bits coated with titanium to reduce friction and increase wear resistance, which prolongs the bit's lifespan.
- Solid Carbide: Extremely hard and heat-resistant bits used primarily in high-precision, industrial manufacturing.
Point Angles and Design
The tip of the twist drill (the point) features cutting edges called lips. The standard point angle is 118°, which works well for soft metals and wood. Harder materials often require a 135° split-point, which centers itself automatically and allows for rapid penetration with minimal pressure.
Usage and Limitations
While twist drills are incredibly versatile and are commonly used in both Twist Drill Bits - The Home Depot and industrial machine shop settings, they are not the ideal tool for every application:
- Metal vs. Wood: Although frequently used for wood, standard twist drills tend to wander, skid, or skate across a wooden surface if a pilot hole isn't first drilled. For pure woodworking, Brad Point Bits are preferred because their sharp center spurs prevent wandering.
- Maintenance: Twist drills must be periodically withdrawn from deep holes to clear built-up swarf to prevent the bit from binding or breaking.
- Sharpening: Dull twist drill bits can be sharpened, but require precision to ensure both cutting lips remain equal in length and centered, otherwise the drill will cut oversized holes
SPEC
|
Material |
Solid tungsten carbide or HSS |
|
Coating |
Uncoated or Coated |
|
Chemical Composition |
10% Co & 90% WC or M2,6542, 4341, M35, M42 |
|
Carbide Grain Size |
1.2 μm |
|
Carbide Hardness (HRA) |
≥70 |
|
Carbide Magnetic Force |
23 (KA/M) |
|
Carbide T.R.S |
3200 (N/mm2) |
|
Carbide Magnetic Saturation |
10.3 (Ms) |
|
Purpose |
Kind of tool to drill the hole |
|
Carbide Density |
14.05 (g/cm3) |
Tungsten Cemented Carbide Grade
Main
Hot Products
Company Information
Kunshan Zhiyi Dingli Cemented Carbide Tool Co., Ltd. produces a comprehensive range of twist drills at our Suzhou factory, serving general machining needs across multiple industries. From HSS standard drills to solid carbide high-performance drills, our product line covers 118 and 135 degree point geometries in sizes from 1mm to 60mm.
We supply twist drills to distributors and end-users across the United States, Russia, Indonesia, Australia, and South America. Our inventory includes the most commonly requested sizes for immediate shipment, reducing lead times for urgent orders.ustomers, such as the United States, Russia, Indonesia, South Korea, Japan, Australia and so on.
Testing Machine
Production Flow Chart
Packing & Delivery
Packing
1>Put the goods encased with plastic bag or plastic case in wooden box/carton/iron box,etc.
2>Other packing will be accept according to your needs.
FAQ
Q1: What is the difference between 118 and 135 degree points?
A1: 118 degrees is standard for soft materials like wood and mild steel. 135 degree split-point is self-centering for harder materials like stainless steel.
Q2: Can you supply reduced shank drills?
A2: Yes, for applications where the shank needs to fit a smaller chuck.
Q3: What coating for aluminum?
A3: Uncoated bright finish or DLC coated for better lubricity and chip release in production.
Q4: Do you carry metric or inch sizes?
A4: Both metric from 1.0mm to 60.0mm and inch from 1/16 to 2 inches.
Q5: Can you make extra-long twist drills?
A5: Yes, with flute lengths up to 300mm. For deeper holes, consider our gun drill series.
About Color Aberration
Product pictures are all physical photography, due to photo-taking technology, light, display parameters, etc., there may be differences between the received physical objects and photos, please refer to the physical.
Cargo Receipt
All our products go through strict inspection and count before shipment. Please check the goods in person when they receive them.
Please refuse to sign and contact us if you find that the CTN number and model is wrong or the product is damaged in transit.
