The T-slot groove cutter (T groove cutter) is a specialized tool for machining T-shaped grooves on mechanical tabletops. It is mainly divided into two types: taper shank T-shaped groove cutter and straight shank T-shaped groove cutter. The material is usually high-speed steel or hard alloy. High-speed steel is suitable for materials with a hardness of HRC30 or below, while hard alloy is used for high-hardness or difficult-to-machine materials. This tool is applicable to the processing of various materials such as aluminum alloy, steel, and stainless steel, and can be compatible with CNC machining centers, engraving machines, and other machines. Its structure adopts a helical and staggered tooth design to ensure smooth cutting. Specifications and parameters include the diameter of the tool body (D4-D32), the number of cutting edges (1-8), the rotational speed (≥500r/min), and the cutting depth (for rough machining: 2.0-8.0mm, for fine machining: 0.5-2.0mm). The eccentric T-shaped groove cutter has the characteristics of small radial run out of the tooth and reusable tool body. Some models adopt a spline positioning groove design to enhance torque transmission performance and support non-standard tool customization and coating treatment.
T-shaped groove cutters can be classified into taper shank T-shaped groove cutters and straight shank T-shaped groove cutters.
Usage: it is used for machining T-shaped grooves on various mechanical tabletops or other structures.
Features and accuracy: it is a specialized tool for machining T-shaped grooves. After a straight groove is machined, it can machine a T-shaped groove with the required accuracy in one operation. The cutting edge of the tool has an appropriate cutting angle, and the teeth are designed as helical and staggered teeth, ensuring smooth cutting and low cutting force.
Specification description: T-shaped groove cutters are generally described in the following aspects of their model: the diameter of the disc and the tooth part (outer diameter), the thickness of the disc (blade length), the number of teeth (blade number), the diameter of the handle (handle diameter), and the total length.
T-shaped groove cutters are generally made of high-speed steel and hard alloy. For processing general easy-to-machine materials (HRC30 or below), high-speed steel can be selected. If the material to be processed is hard or difficult to machine, it is best to use hard alloy. T-shaped groove cutters made of hard alloy also come in two types: integral and welded. In terms of cost performance, welded alloy (embedded alloy) is more cost-effective. If the processing requirements are high and the accuracy is high, it is recommended to use integral hard alloy for manufacturing. However, the price will be much higher.
SPEC
|
Material |
Solid tungsten carbide |
|
Coating |
Uncoated or TICN, TIALN, AlTiN or Nano coated....... |
|
Chemical Composition |
10% Co & 90% WC |
|
Grain Size |
1.2 μm |
|
Hardness (HRA) |
≥90 |
|
Magnetic Force |
23 (KA/M) |
|
T.R.S |
3200 (N/mm2) |
|
Magnetic Saturation |
10.3 (Ms) |
|
Purpose |
Kind of tool to milling |
|
Density |
14.05 (g/cm3) |
Tungsten Cemented Carbide Grade
