3F flat head carbide end mill use for process aluminum, high performance type tool feature description:
1. The tool size is manufactured according to our company's standards and can accept non-standard customization;
2. The edge diameter tolerance is 0/-0.02, and the handle size tolerance is H6;
3. The bottom edges are all designed as symmetrical edges with an edge inclination angle;
4. The helix angle is 45 degrees.
The applicable processing methods for the tool: 3F end mill is suitable for processing methods such as slotting, side milling, heavy cutting, and finishing.
Suitable for high-speed machining, both with coolant and dry cutting conditions
Equipment used: CNC machining center, CNC machine, engraving machine, engraving machine.
SPEC
|
Material |
Solid tungsten carbide |
|
Coating |
Uncoated or DLC coated |
|
Chemical Composition |
10% Co & 90% WC |
|
Grain Size |
1.2 μm |
|
Hardness (HRA) |
≥90 |
|
Magnetic Force |
23 (KA/M) |
|
T.R.S |
3200 (N/mm2) |
|
Magnetic Saturation |
10.3 (Ms) |
|
Purpose |
Kind of tool to milling |
|
Density |
14.05 (g/cm3) |
Tungsten Cemented Carbide Grade
Main
Hot Products
Company Information
Kunshan Zhiyi Dingli Cemented Carbide Tool Co., Ltd. manufactures three-flute flat end mills at our Suzhou facility, optimized for aluminum and non-ferrous metal machining. Our 3F end mills feature 45-degree helix angle and 0/-0.02mm edge diameter tolerance for CNC machining centers in the automotive, electronics, and consumer goods industries.
Our 3-flute end mills are supplied to CNC machining facilities in the United States, Canada, Mexico, and throughout Europe. We offer just-in-time delivery arrangements for regular customers with established demand patterns.
Production Flow Chart
Packing & Delivery
Packing
1>Put the goods encased with plastic bag or plastic case in wooden box/carton/iron box,etc.
2>Other packing will be accept according to your needs.
FAQ
Q1: Advantages of 3-flute design?
A1: Best compromise between chip clearance better than 4-flute and surface finish better than 2-flute. Excellent for aluminum machining.
Q2: Can these be used for slotting?
A2: Yes, designed for slotting, side milling, and plunge cutting with 45 degree helix angle. Use climb milling for best results.
Q3: What diameter tolerance do you hold?
A3: 0 to -0.02mm cutting diameter with H6 shank tolerance for consistent tool holder grip.
Q4: What coating for aluminum?
A4: Uncoated or DLC coated. DLC provides better lubricity. TiAlN can react with aluminum at cutting temperatures.
Q5: Maximum RPM rating?
A5: Up to 40000 RPM when balanced. We recommend dynamic balancing above 20000 RPM for high-speed machining.
