The spiral point tap (often called a "gun tap") features a straight flute with an angled notch at the tip that pushes chips forward, ahead of the cut. It is ideal exclusively for through holes-where the hole completely penetrates the workpiece-as it prevents flute clogging and minimizes tap breakage.
Key Features and Uses
Chip Direction:
Drives swarf forward through the hole. Because of this, it should never be used in blind holes, as chips would become compacted at the bottom.
Increased Strength:
Since the flutes are only used to push chips forward, they can be shallower, giving the tap a larger cross-sectional area and making it stronger than spiral flute taps.
Applications:
Excellent for production tapping in ductile materials like aluminum, copper, brass, and mild steels.
SPEC
|
Material |
HSS or HSS-Co |
|
Coating |
Uncoated or TiN or TiCN coated |
|
Chemical Composition |
Haven't Co or 5% Co |
|
Grain Size |
4 μm |
|
Hardness (HRA) |
≥60 |
|
Magnetic Force |
13 (KA/M) |
|
T.R.S |
1200 (N/mm2) |
|
Magnetic Saturation |
5 (Ms) |
|
Purpose |
Kind of tool to process thread |
|
Density |
8 (g/cm3) |
Tungsten Cemented Carbide Grade
